Li-MnO2 Battery

Model (V)
Operating Voltage
(mm)
Max Dimension
(mAh)
Standard Capcity
(mA)
Max constant  current
(℃)
Using Temperature
CP073040 3 0.9*40.5*31 50 1 -20~60
CP151350 3 1.5*13*50 140 2 -20~60
CP203047 3 2.2*47.5*35.5 650 200 -20~60
CP204440 3 2.2*44.5*40.5 500 45 -20~60
CP223830 3 2.3*39*30 400 60 -20~60
CP224136 3 2.5*41*36 650 150 -20~60
CP224147 3 2.2*48.3*45.5 800 200 -20~60
CP305050 3 3.2*50.5*56.5 1600 600 -20~60
CP502025 3 5.2*25.5*20.5 400 30 -20~60
CP502425 3 5.2*24.5*25.5 550 40 -20~60
CP502440 3 5.2*41*24.5 1200 120 -20~60
CP505050 3 5.2*50.5*50.5 3000 1500 -20~60
CP504644 3 5.2*46.5*44.5 2400 400 -20~60
CP952434 3 9.7*24.5*35 1600 300 -20~60
CP1003665 3 10*36.3*66 6000 2000 -20~60
CR10120P 3 Ø10*12 140 15 -20~60
CP9V 9 49.5*18*27.3 1200 120 -20~60
Advantage :
High capacity density, light weight
High safety, no explosion, meets IEC86-4 safety standards
Environmentally friendly products, no leakage, no heavy metals, no pollution
The thinnest thickness can be up to 0.4mm
Easy to make a variety of shapes, can be customized according to customer requirements
Stable high operating voltage
-20~+60℃:Wide operating temperature range, -20~+60°C
Self-discharge rate is low, annual self-lowing rate is lower than 2%
No hysteresis, good pulse discharge performance

Application: smart meters, water meters, electricity meters, gas meters, RFID,
automotive electronics (TPMS), RAM emergency CMOS circuits, oil exploration,
medical equipment, burglar alarm lights for civilian use, and aerospace, in
a wide range of defense and military fields, Various military radio stations
such as underwater weapons, sonar, and navigation.
